1. Materials:

    a. Housing: LCP+30%G/F,UL94 V-0、Black;

    b. contact: Copper Alloy(Brass), T=0.30mm'

       finish: Gold plating on Contact area,

             Tin Plated on Solder area,

             Ni UNDER PLATED overall;

  2. Electrical characteristics:

    a. Current rating: 1.0 AMP per contact;

    b.  Current voltage: 30V AC/DC

    c. Dielectric withstanding voltage: 500V AC 1Minute;

    d. Insulation resistance: 1000 Megohms at 500V DC Min;

    e. Contact resistance: 30 milliohms Max (initial);

  3.Mechanical Characterisrics:

    a:Insertion Force:  1.7N per contact pair Max.

    b:Extraction Force: 0.1N per contact pair Min.

    c.Durability rating: 100 Cycles

  4. Operating temperature:-25 oC ~ +85 oC
