 1. Materials:

  a. Housing:

      High Temperature Thermoplastic(UL94-HB Min.);

  b. contact:

       Copper Alloy, Gold plating over Nickel on

       contact area; Tin plating over Nickel on terminal;

  c. Fork(optional): SPCC, Nickel plated.

2. Electrical characteristics:

 a. Current rating: 1.0 AMP per contact;

 b. Dielectric withstanding voltage: 500V AC 1Minute;

 c. Insulation resistance: 1000 Megohms at 500V DC Min;

   d. Contact resistance: 30 milliohms Max (initial);
3. Mechanical Characterisrics:

     a. Insertion Force: 11.0 Kgf Max.

b. Extraction Force: 0.6Kgf Min.

c. Durability rating: 50 Cycles
